ISP Optics 锗平凸透镜

ISP Optics 锗平凸透镜

￥ 0.00
0.00


ISP Optics 锗平凸透镜对长波红外(LWIR)光谱提供高透过和低吸收，使其非常适合热成像应用。锗(Ge)具有化学惰性、不溶于水、努氏硬度为780，这些特点使其非常适合需要坚固光学元件的应用。然而，锗(Ge)会发生热失控，应在低于100℃的温度下使用。ISP 锗平凸透镜的无镀膜版本在 2-16µm 的透射范围广，宽带增透镀膜(BBAR)版本可增强在中波红外(MWIR)和长波红外(LWIR)波段的透射。


  • 是热成像应用的理想选择

  • 未镀膜透过范围为 2 - 16µm

  • 可提供无镀膜或针对 3 - 12µm 的 BBAR 镀膜

  • 由于锗的原材料供应链中断，我们的锗材料产品交付周期可能会延长，价格也可能会发生变化。如需了解更多信息，请向我们的 客服团队进行咨询。

  • Edmund Optics 的该零件号剩余库存有限，一旦耗尽，由于没有原材料，将无法供应。 请联系我们的产品支持工程师，帮助您找到满足您需求的替代解决方案。客户服务部门可为您提供最新的价格和供应情况。


                                                       产品

标题产品编码Dia. (mm)EFL (mm)涂层涂层规格基底表面质量Irregularity (P-V) @ 10.6μmFL Tolerance (%)中心偏（弧分）CT (mm)ET (mm)半径 R1 (mm)CA (mm)
12.7mm Dia. x 50.8mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-12-5024-84412.70 +0.00/-0.1350.80 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.10 ±0.202.00 151.01 11.43
25.4mm Dia. x 63.5mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-6324-84625.40 +0.00/-0.1363.50 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.40 ±0.202.00 188.80 22.86
25.4mm Dia. x 76.2mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-7624-84725.40 +0.00/-0.1375.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.40 ±0.202.00 229.10 22.86
25.4mm Dia. x 127mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-12724-84825.40 +0.00/-0.13127.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 376.70 22.86
25.4mm Dia. x 150mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-15024-84925.40 +0.00/-0.13150.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 452.90 22.86
25.4mm Dia. x 200mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-20024-85025.40 +0.00/-0.13200.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 597.16 22.86
25.4mm Dia. x 254mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-25-25424-85125.40 +0.00/-0.13254.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.10 ±0.202.00 748.20 22.86
38.1mm Dia. x 50.8mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-5024-85238.10 +0.00/-0.1350.80 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 3.20 ±0.202.00 151.01 34.29
38.1mm Dia. x 63.5mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-6324-85338.10 +0.00/-0.1363.50 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 3.00 ±0.202.00 188.80 34.29
38.1mm Dia. x 76.2mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-7624-85438.10 +0.00/-0.1375.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.80 ±0.202.00 229.10 34.29
38.1mm Dia. x 100mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-10024-85538.10 +0.00/-0.13100.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.60 ±0.202.00 299.90 34.29
38.1mm Dia. x 127mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-12724-85638.10 +0.00/-0.13127.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.50 ±0.202.00 376.70 34.29
38.1mm Dia. x 254mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-25424-85838.10 +0.00/-0.13254.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 748.20 34.29
38.1mm Dia. x 1000mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-38-100024-85938.10 +0.00/-0.131,000.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.00 ±0.202.00 2,965.00 34.29
50.8mm Dia. x 76.2mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-50-7624-86050.80 +0.00/-0.1375.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 4.00 ±0.202.60 229.10 45.72
50.8mm Dia. x 100mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-50-10024-86150.80 +0.00/-0.13100.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 3.60 ±0.202.50 299.90 45.72
50.8mm Dia. x 127mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-50-12724-86250.80 +0.00/-0.13127.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 3.30 ±0.202.50 376.70 45.72
50.8mm Dia. x 200mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-50-20024-86350.80 +0.00/-0.13200.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 3.00 ±0.202.50 597.16 45.72
50.8mm Dia. x 300mm FL, Uncoated, ISP Optics Germanium (Ge) PCX Lens | GE-PX-50-30024-86450.80 +0.00/-0.13300.00 @10.6µmUncoated
Germanium (Ge) 60-40 λ/20 ±2 <3 2.90 ±0.202.50 855.10 45.72
25.4mm Dia. x 76.2mm FL, 3 - 12μm Coated, ISP Optics Germanium (Ge) PCX Lens | AR312-GE-PX-25-7624-87225.40 +0.00/-0.1375.00 @10.6µmBBAR (3000-12000nm) Ravg <5.0% @ 3 - 12μm Germanium (Ge) 60-40 λ/20 ±2 <3 2.40 ±0.202.00 229.10 22.86
25.4mm Dia. x 127mm FL, 3 - 12μm Coated, ISP Optics Germanium (Ge) PCX Lens | AR312-GE-PX-25-12724-87425.40 +0.00/-0.13127.00 @10.6µmBBAR (3000-12000nm) Ravg <5.0% @ 3 - 12μm Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 376.70 22.86
25.4mm Dia. x 152.4mm FL, 3 - 12μm Coated, ISP Optics Germanium (Ge) PCX Lens | AR312-GE-PX-25-15024-87525.40 +0.00/-0.13150.00 @10.6µmBBAR (3000-12000nm) Ravg <5.0% @ 3 - 12μm Germanium (Ge) 60-40 λ/20 ±2 <3 2.20 ±0.202.00 452.90 22.86
25.4mm Dia. x 254mm FL, 3 - 12μm Coated, ISP Optics Germanium (Ge) PCX Lens | AR312-GE-PX-25-25424-87725.40 +0.00/-0.13254.00 @10.6µmBBAR (3000-12000nm) Ravg <5.0% @ 3 - 12μm Germanium (Ge) 60-40 λ/20 ±2 <3 2.10 ±0.202.00 748.20 22.86
25.4mm Dia. x 500mm FL, 3 - 12μm Coated, ISP Optics Germanium (Ge) PCX Lens | AR312-GE-PX-25-50024-87825.40 +0.00/-0.13500.00 @10.6µmBBAR (3000-12000nm) Ravg <5.0% @ 3 - 12μm Germanium (Ge) 60-40 λ/20 ±2 <3 2.00 ±0.202.00 1,500.00 22.86
