自由空间光隔离器

自由空间光隔离器

￥ 0.00
0.00


自由空间光隔离器采用特殊的设计和制造工艺，提供卓越的性能，具有高隔离度，透射和功率密度。它可以有效减少二极管激光系统的外部空腔反馈，并截止自由空间光纤耦合的反射。自由空间光隔离器增加了光学系统的功率稳定性，能够消除反馈，避免对敏感光学元件的造成损伤。这款光隔离器拥有最先进的保护功能，可用于稳定激光，适用于各类苛刻的激光应用。


  • 高达67隔离度，稳定性极佳

  • 最大功率下损耗很小

  • 4.7mm 输入光圈

                                          产品

标题产品编码CA (mm)DWL (nm)最小传输 (%)工作温度 (°C)透射率 (%) 类型波长范围 (nm)方式Damage Threshold, By Design典型隔离 @ 设计波长 (dB)
405NM SINGLE STAGE FARADAY ISOLATOR35-9694.7 405 85 +15 to +40 92 (typical) Single Stage Optical Isolator 395 - 425 Faraday 40 W, 4 kW/cm2 @ DWL 43
460nm Single Stage Free-Space Optical Isolator72-6304.7 460 >85 +15 to +40 92 Single Stage Optical Isolator 450 - 480 Faraday 40 W, 4 kW/cm2 @ DWL 43
650nm Single Stage Free-Space Optical Isolator35-9704.7 650 >85 +15 to +40 92 Single Stage Optical Isolator 630 - 670 Faraday 40 W, 4 kW/cm2 @ DWL 43
690nm Single Stage Free-Space Optical Isolator35-9714.7 690 >85 +15 to +40 92 Single Stage Optical Isolator 670 - 710 Faraday 40 W, 4 kW/cm2 @ DWL 43
780NM SINGLE STAGE FARADAY ISOLATOR35-9734.7 780 85 +15 to +40 92 (typical) Single Stage Optical Isolator 750 - 810 Faraday 40 W, 4 kW/cm2 @ DWL 43
660NM DUAL STAGE FARADAY ISOLATOR35-9804.7 660 80 +15 to +40 90 (typical) Dual Stage Optical Isolator 640 - 680 Faraday 40 W, 4 kW/cm2 @ DWL 67
700nm Dual Stage Free-Space Optical Isolator35-9814.7 700 >80 +15 to +40 90 Dual Stage Optical Isolator 680 - 720 Faraday 40 W, 4 kW/cm2 @ DWL 67
730nm Single Stage Free-Space Optical Isolator35-9724.7 730 >85 +15 to +40 92 Single Stage Optical Isolator 710 - 750 Faraday 40 W, 4 kW/cm2 @ DWL 43
740nm Dual Stage Free-Space Optical Isolator35-9824.7 740 >80 +15 to +40 90 Dual Stage Optical Isolator 720 - 760 Faraday 40 W, 4 kW/cm2 @ DWL 67
780NM DUAL STAGE FARADAY ISOLATOR35-9834.7 780 80 +15 to +40 90 (typical) Dual Stage Optical Isolator 760 - 805 Faraday 40 W, 4 kW/cm2 @ DWL 67
820NM DUAL STAGE FARADAY ISOLATOR35-9844.7 820 80 +15 to +40 90 (typical) Dual Stage Optical Isolator 800 - 865 Faraday 40 W, 4 kW/cm2 @ DWL 67
835nm Single Stage Free-Space Optical Isolator35-9744.7 835 >85 +15 to +40 92 Single Stage Optical Isolator 810 - 860 Faraday 40 W, 4 kW/cm2 @ DWL 43
880nm Dual Stage Free-Space Optical Isolator35-9854.7 880 >80 +15 to +40 90 Dual Stage Optical Isolator 860 - 930 Faraday 40 W, 4 kW/cm2 @ DWL 67
885nm Single Stage Free-Space Optical Isolator35-9754.7 885 >85 +15 to +40 92 Single Stage Optical Isolator 860 - 910 Faraday 40 W, 4 kW/cm2 @ DWL 43
945nm Single Stage Free-Space Optical Isolator35-9764.7 945 >85 +15 to +40 92 Single Stage Optical Isolator 905 - 985 Faraday 40 W, 4 kW/cm2 @ DWL 43
950nm Dual Stage Free-Space Optical Isolator35-9864.7 950 >80 +15 to +40 90 Dual Stage Optical Isolator 930 - 995 Faraday 40 W, 4 kW/cm2 @ DWL 67
1015nm Single Stage Free-Space Optical Isolator72-6314.7 1015 >85 +15 to +40 92 Single Stage Optical Isolator 1015 Faraday 40 W, 4 kW/cm2 @ DWL 43
1020nm Dual Stage Free-Space Optical Isolator35-9874.7 1020 >80 +15 to +40 90 Dual Stage Optical Isolator 995 - 1050 Faraday 40 W, 4 kW/cm2 @ DWL 67
1070NM DUAL STAGE FARADAY ISOLATOR35-9884.7 1070 80 +15 to +40 90 (typical) Dual Stage Optical Isolator 1050 - 1100 Faraday 40 W, 4 kW/cm2 @ DWL 67
1150nm Single Stage Free-Space Optical Isolator35-9774.7 1150 >85 +15 to +40 92 Single Stage Optical Isolator 1100 - 1200 Faraday 10 W, 320 W/cm2 @ DWL 43
1250nm Single Stage Free-Space Optical Isolator35-9784.7 1250 >85 +15 to +40 92 Single Stage Optical Isolator 1200 - 1300 Faraday 10 W, 320 W/cm2 @ DWL 43
1350nm Single Stage Free-Space Optical Isolator35-9794.7 1350 >85 +15 to +40 92 Single Stage Optical Isolator 1300 - 1400 Faraday 10 W, 320 W/cm2 @ DWL 43
