熔融石英楔形棱镜
￥ 0.00
0.00
TECHSPEC® 熔融石英楔形棱镜专为需要 UV-VIS 或一至四层 Nd:YAG 谐波增透膜的一系列激光束定向应用而设计. 它们已经过优化，使用严格控制的规格以确保系统具有最高的性能水平，包括λ/10 表面平面度、20-10 表面质量以及 15 弧秒楔形公差。Nd:YAG 镀膜版本具有高透射率并保证特定于设计波长的激光损伤阈值。TECHSPEC® 熔融石英楔形棱镜采用楔形设计，使激光光束路径偏离 0.5° – 5°. 通过使用两个楔形棱镜来创建一个里斯莱棱镜对，自定义光束转向可达到楔形偏差的两倍。低热膨胀系数可确保在高功率激光应用中实现精确的光束转向.
将激光束路径偏移 0.5° - 5.0°
非常适用于 250 至 1064nm 的 UV 至 NIR 光束偏转应用
保证激光损伤阈值，适用于 Nd:YAG 版本
产品
| 标题 | 产品编码 | 角度容差（弧秒） | 涂层 | DWL (nm) | Dia. (mm) | 基底 | 表面质量 | 厚度 (mm) | 类型 | 倒角 | 图像定位 |
| PRISM WEDGE FS 0.5 DEG 12.5MM UNCTD | 35-842 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 0.5 DEG 12.5MM UV VIS | 35-849 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-073 | 30 | Laser V-Coat (355nm) | 355 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-089 | 30 | Laser V-Coat (532nm) | 532 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-123 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 1 DEG 12.5MM UNCTD | 35-843 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 1 DEG 12.5MM UV VIS | 35-850 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 266nm Laser V-Coat | 39-058 | 30 | Laser V-Coat (266nm) | 266 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-074 | 30 | Laser V-Coat (355nm) | 355 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-124 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 1.5 DEG 12.5MM UNCTD | 35-844 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 1.5 DEG 12.5MM UV VIS | 35-851 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 1.5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-075 | 30 | Laser V-Coat (355nm) | 355 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 1.5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-125 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 2 DEG 12.5MM UNCTD | 35-845 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 2 DEG 12.5MM UV VIS | 35-852 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 2° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-126 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 2.5 DEG 12.5MM UNCTD | 35-846 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 2.5 DEG 12.5MM UV VIS | 35-853 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 2.5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-077 | 30 | Laser V-Coat (355nm) | 355 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 4 DEG 12.5MM UNCTD | 35-847 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 4 DEG 12.5MM UV VIS | 35-854 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 4° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-128 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| PRISM WEDGE FS 5 DEG 12.5MM UNCTD | 35-848 | 30 | Uncoated | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| PRISM WEDGE FS 5 DEG 12.5MM UV VIS | 35-855 | 30 | UV-VIS (250-700nm) | 355 | 12.50 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 12.5mm Dia. 5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-079 | 30 | Laser V-Coat (355nm) | 355 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 12.5mm Dia. 5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-129 | 30 | Laser V-Coat (1064nm) | 1064 | 12.50 | Fused Silica (Corning 7980) | 20-10 | 1.50 | Protective bevel as needed | Beam Deviation | |
| 0.5度，未镀膜熔融石英楔形棱镜 | 84-859 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 0.5度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-636 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-080 | 15 | Laser V-Coat (355nm) | 355 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-116 | 15 | Laser V-Coat (532nm) | 532 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 0.5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-130 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 1.0度，未镀膜熔融石英楔形棱镜 | 84-860 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 1.0度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-637 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-081 | 15 | Laser V-Coat (355nm) | 355 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-117 | 15 | Laser V-Coat (532nm) | 532 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 1° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-131 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 1.5度，未镀膜熔融石英楔形棱镜 | 84-861 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 1.5度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-638 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 1.5° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-082 | 15 | Laser V-Coat (355nm) | 355 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 1.5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-132 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 2.0度，未镀膜熔融石英楔形棱镜 | 84-862 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 2.0度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-639 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 2° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-083 | 15 | Laser V-Coat (355nm) | 355 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 2° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-119 | 15 | Laser V-Coat (532nm) | 532 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 2° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-133 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 2.5度，未镀膜熔融石英楔形棱镜 | 84-863 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 2.5度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-640 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 2.5° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-120 | 15 | Laser V-Coat (532nm) | 532 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 2.5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-134 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 4 度，未镀膜熔融石英楔形棱镜 | 84-864 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 4.0度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-641 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 4° Beam Dev. Fused Silica Wedge Prism 266nm Laser V-Coat | 39-071 | 15 | Laser V-Coat (266nm) | 266 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 4° Beam Dev. Fused Silica Wedge Prism 355nm Laser V-Coat | 39-086 | 15 | Laser V-Coat (355nm) | 355 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 4° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-135 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 5.0°光束偏离角，熔融石英楔角棱镜，未镀膜 | 84-865 | 15 | Uncoated | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 5.0度光束偏离角，镀紫外线-VIS膜，熔融石英楔形棱镜 | 89-642 | 15 | UV-VIS (250-700nm) | 355 | 25.00 +0.00/-0.10 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Wedge Prism | Protective bevel as needed | Beam Deviation |
| 25mm Dia. 5° Beam Dev. Fused Silica Wedge Prism 266nm Laser V-Coat | 39-072 | 15 | Laser V-Coat (266nm) | 266 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 5° Beam Dev. Fused Silica Wedge Prism 532nm Laser V-Coat | 39-122 | 15 | Laser V-Coat (532nm) | 532 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation | |
| 25mm Dia. 5° Beam Dev. Fused Silica Wedge Prism 1064nm Laser V-Coat | 39-136 | 15 | Laser V-Coat (1064nm) | 1064 | 25.00 | Fused Silica (Corning 7980) | 20-10 | 3.00 | Protective bevel as needed | Beam Deviation |
